TensorRT-LLM vs vLLM on 4×H100: The Concurrency Crossover｜4×H100 上的 TensorRT-LLM 與 vLLM：Concurrency crossover

2026-05-31 · updated 2026-07-21 · LLM serving / NVIDIA stack

TensorRT-LLM production serving · TensorRT-LLM production serving 架構 · Source: NVIDIA Developer

The trtllm-triton-serving harness takes an open-weights Hugging Face checkpoint through a TensorRT-LLM engine build and exposes it with trtllm-serve or Triton. The matched-work benchmark compares that stack with vLLM on 4× H100 connected by NVLink.¹

trtllm-triton-serving harness 會把 Hugging Face 的開放權重 checkpoint 建成 TensorRT-LLM engine，再透過 trtllm-serve 或 Triton 對外服務。Matched-work benchmark 則在 NVLink 連接的 4× H100 上，拿這套 stack 和 vLLM 比較。¹

1. The serving pipeline｜Serving pipeline

The path from checkpoint to endpoint has four stages. A choice at any stage can change latency, throughput, or accuracy:

Checkpoint 到 endpoint 分成四個階段；任何一階段的設定都可能改變 latency、throughput 或 accuracy：

1. Checkpoint: a Hugging Face model.
   Checkpoint：Hugging Face model。
2. Engine build: compile a TensorRT-LLM engine for a selected tensor-parallel degree, precision, and batching policy.
   Engine build：依指定的 tensor-parallel degree、precision 與 batching policy 編譯 TensorRT-LLM engine。
3. Model repository: wrap the engine in a Triton tensorrt_llm backend repository.
   Model repository：把 engine 包進 Triton tensorrt_llm backend repository。
4. Serving and load test: expose an OpenAI-compatible endpoint and drive it with controlled concurrency.
   Serving 與 load test：提供 OpenAI-compatible endpoint，再用受控 concurrency 施加負載。

TensorRT-LLM builds an engine for a selected GPU architecture, TP degree, precision, and batching configuration. vLLM makes more of those decisions at runtime, so the two stacks trade build-time specialization for runtime flexibility.²

TensorRT-LLM 會針對指定的 GPU architecture、TP degree、precision 與 batching configuration 建立 engine。vLLM 則在 runtime 做更多決策；兩套 stack 的差別，是 build-time specialization 與 runtime flexibility 的取捨。²

2. Tensor parallelism (TP)｜Tensor parallelism（TP）

When a model does not fit on one GPU—or when the target is lower latency—TensorRT-LLM can shard each layer across GPUs. On a 4× H100 NVLink host, TP=4 introduces all-reduce communication across all four GPUs during each forward pass.

模型放不進單張 GPU，或目標是降低 latency 時，TensorRT-LLM 可以把每一層切到多張 GPU。4× H100 NVLink 主機使用 TP=4 時，每次 forward pass 都會在四張 GPU 間執行 all-reduce。

On this fabric, all-reduce reaches about 77% of the NVLink budget (see the separate NVLink-wall notes). Prefill uses large tensors and benefits from bandwidth. Decode communicates one token at a time and can hit the small-message latency floor; adding TP beyond that point can make decode slower.

在這組 fabric 上，all-reduce 約達 NVLink budget 的 77%（見另一篇 NVLink-wall 筆記）。Prefill 使用大 tensor，能受益於頻寬；decode 一次只處理一個 token，可能撞上小訊息 latency 下限。超過該點後再增加 TP，反而可能讓 decode 變慢。

Choose TP for the message sizes and latency regime of the deployed workload.

TP 應依部署 workload 的 message sizes 與 latency regime 選擇。

3. Precision: FP16 vs FP8｜Precision：FP16 與 FP8

This benchmark compares FP16 and FP8 on Hopper:

這份 benchmark 比較 Hopper 上的 FP16 與 FP8：

Precision	Memory／記憶體	Throughput／吞吐量	Accuracy risk／準確度風險
FP16	baseline／基準	baseline／基準	reference／參考值
FP8	~½ weights + KV cache／約一半的 weights 與 KV cache	higher／較高	small, model-dependent／幅度小但依模型而異

FP8 uses Hopper Transformer Engine and reduces weight and KV-cache storage. The accuracy delta must be measured on the target workload, under the same harness as the throughput result.

FP8 使用 Hopper Transformer Engine，並減少 weight 與 KV-cache storage。Accuracy delta 必須在目標 workload 上量測，而且要和 throughput 使用同一套 harness。

4. Continuous batching and paged KV cache｜Continuous batching 與 paged KV cache

Two features shape the production configurations compared here:

本文比較的 production configurations 都包含兩項功能：

• In-flight (continuous) batching lets new requests join a running batch at the next iteration instead of waiting for it to drain. Both vLLM and TensorRT-LLM support it.
  In-flight（continuous）batching 允許新 request 在下一個 iteration 加入目前 batch，不必等整批清空；vLLM 與 TensorRT-LLM 都支援。
• Paged KV cache allocates cache in pages rather than reserving the worst-case sequence length for each request, allowing more concurrent sequences to fit.
  Paged KV cache 以 pages 分配 cache，不會為每個 request 預留 worst-case sequence length，因此能容納更多 concurrent sequences。

Results without these features describe static batching rather than the production configurations measured here.

未啟用這兩項功能的結果描述的是 static batching，不能和本文的 production configurations 直接比較。

5. Match the generated work｜讓兩套 stack 生成相同工作量

Completion length is a confounder: a stack that emits fewer tokens can appear faster while doing less work. The harness therefore forces every request to decode exactly 256 tokens with ignore_eos=True and matched minimum and maximum token limits.

Completion length 是一個 confounder：某套 stack 產生較少 tokens 時，即使只是少做工作，看起來也會比較快。因此，harness 使用 ignore_eos=True 和一致的最小／最大 token limits，強制每個 request 都 decode 256 tokens。

Report all metrics at matched concurrency:

所有指標都必須在相同 concurrency 下回報：

• Throughput in total tokens/s.
  Throughput：總 tokens/s。
• TTFT (time to first token), dominated by prefill.
  TTFT（time to first token）：主要受 prefill 影響。
• Inter-token latency, dominated by decode.
  Inter-token latency：主要受 decode 影響。

6. Triton as the deployment surface｜以 Triton 作為部署介面

The benchmark uses TensorRT-LLM’s OpenAI server, trtllm-serve. The repository also includes a Triton tensorrt_llm backend model repository for deployments that need Triton metrics, health checks, ensembles, or multi-model hosting.³

Benchmark 使用 TensorRT-LLM 的 OpenAI server，也就是 trtllm-serve。Repository 另附 Triton tensorrt_llm backend model repository，供需要 Triton metrics、health checks、ensembles 或 multi-model hosting 的部署使用。³

The Triton path can place tokenizer, engine, and detokenizer stages in one ensemble and expose them through a shared control plane.

Triton path 可以把 tokenizer、engine 與 detokenizer 放進同一個 ensemble，再透過共用 control plane 對外服務。

7. Measured crossover on 4×H100｜4×H100 上的實測 crossover

On the matched-work sweep, TensorRT-LLM led at low-to-mid concurrency and vLLM led at high concurrency:

Matched-work sweep 顯示 TensorRT-LLM 在 low-to-mid concurrency 領先，vLLM 則在 high concurrency 領先：

• TensorRT-LLM with CUDA Graphs leads at low-to-mid concurrency. Ahead-of-time specialization and graph capture reduce per-iteration launch overhead when batches are small, lowering TTFT and inter-token latency.
  TensorRT-LLM 加 CUDA Graphs 在 low-to-mid concurrency 領先。 Batch 較小時，ahead-of-time specialization 與 graph capture 會降低每個 iteration 的 launch overhead，進而降低 TTFT 與 inter-token latency。
• vLLM leads at high concurrency. In the throughput-saturated regime, its scheduler keeps the GPU packed and the launch-overhead advantage no longer determines the result.
  vLLM 在 high concurrency 領先。 進入 throughput-saturated regime 後，它的 scheduler 能維持 GPU 飽和，launch-overhead 優勢也不再主導結果。

One configuration bug changed this curve: CUDA Graphs only help when the graph setting is actually enabled. A misconfigured run made TensorRT-LLM look only slightly faster; fixing the setting moved the low-concurrency result substantially.

一個 configuration bug 曾經改變整條曲線：只有真正啟用 graph setting 時，CUDA Graphs 才有效。設定錯誤的 run 讓 TensorRT-LLM 看起來只快一點；修正後，low-concurrency 結果明顯移動。

Choose from the measured load regime: TensorRT-LLM with CUDA Graphs for the latency-sensitive low/mid-concurrency range, and vLLM for the tested high-concurrency throughput range. Rerun the sweep on the target hardware before carrying over the crossover.

選擇要依實測 load regime：latency-sensitive 的 low／mid-concurrency 範圍使用 TensorRT-LLM 加 CUDA Graphs；本文測試的 high-concurrency throughput 範圍則由 vLLM 領先。把 crossover 套到其他系統前，應先在目標硬體上重跑 sweep。

→ Full pipeline, Triton model repository, and matched-work harness:
完整 pipeline、Triton model repository 與 matched-work harness： github.com/waynehacking8/trtllm-triton-serving

---

1. TensorRT-LLM + Triton serving benchmark, the primary artifact for engine configs, the matched-work harness, and the measured crossover.／Engine configs、matched-work harness 與實測 crossover 的主要來源。 ↩↩

2. TensorRT-LLM documentation, NVIDIA’s engine-build and runtime reference.／NVIDIA 的 engine-build 與 runtime 文件。 ↩↩

3. Triton Inference Server documentation, NVIDIA’s model-repository, scheduling, metrics, and protocol reference.／NVIDIA 的 model repository、scheduling、metrics 與 protocol 文件。 ↩↩
